Mindray BeneView T5 Service Manual

6-1
6 Parts
6.1 Introduction
This chapter contains the exploded views and parts lists of the main unit, satellite module
rack and the parameter modules of the patient monitor. It helps the engineers to identify the
parts during disassembling the patient monitor and replacing the parts.
Hardware architecture of the main unit is shown below:
Remark: In the following tables, the P/N with the mark * is the specified P/N for DPM6
Standard configuration model.

Mindray BeneView T5 Specifications

General

Brand	Mindray
Model	BeneView T5
Category	Heart Rate Monitor
Language	English
