Mindray BeneView T5 - Removing the Wireless AP Assembly

208 pages

To Next Page

To Previous Page

5-2

5.3 Disassembling Procedure

5.3.1 Removing the Recorder

1. Open the recorder door and unscrew the two M3×6 screws.

2. Pull the two clips in the directions as indicated and meanwhile pull out the recorder.

NOTE

z Be sure not to damage the connecting cables or connectors when pulling out the

recorder.
