Mindray BeneView T5 Service Manual

6-47
5
9201-20-36009-51 or
9201-20-35917-51(configured
with Dlink AP)
Wireless network card installation board (ASUS)
Wireless network card installation board
(DLINK)
1
6 9201-20-36110 Overlay of wireless network card fixed board 1
7
0000-10-10777 or
0000-10-11296
Wireless AP 54Mbps mini-type (ASUS)
Wireless AP 2.4GHz 54Mbps(DLINK)
1
6.9 Replaceable Parts
To replace the parts, please refer to 5 Repair and Disassem
bly and the exploded views above.
NOTE
z Here we list most replaceable parts. If you need more parts, please contact our
Customer Service Department.
6.9.1 Main Unit
P/N Description Qty
Front housing assembly
0000-10-11020 Backlight board 1
022-000014-00 or
022-000001-00
TPI inverter 1
0000-10-10752
LCD screen (SHARP）
1
0010-10-42633
LCD screen（AU）
1
0000-10-10799 Touchscreen 12.1” 1
0000-10-10749
（optional）
Touchscreen 12.1” 1
6800-30-50082 Touchscreen control board 1
6800-30-51095
（optional）
Touchscreen control board
（should be used in connection with the optional
touchscreen 0000-10-10749）
1
801-6802-00024-00 Button (AU 12.1” screen G121SN01+anti-glare screen) 1
801-6802-00025-00 Button (AU 12.1” screen G121SN01+touchscreen) 1
801-6802-00011-00 Alarm LED board 1
