6-23
043-004053-00
9
6800-20-50262 or
049-000651-00
Rubber washer 1
10
6800-20-50251 or
043-004051-00
Handle 1
11
6800-20-50252 or
043-004052-00
Side plate, left 1
12 6800-20-50263 Cushion 4
6.5.2 SMR Inside Assembly
Exploded View
Parts List
SN P/N Description Qty
1 6800-20-50519 Insulating plate 1
2 9201-20-36010 Torsion spring washer 2
3 6800-20-50256 Light conducting pole 1
4 6800-20-50261 Contact spring 16
5 6800-21-51100 Contact screw 16
