Mindray BeneView T5 Service Manual

6-6
9 M04-004012--- Crosshead screw M3×6 13
10
6802-30-66902 or
6802-30-66773(optional)
12.1" LCD assembly (touchscreen) 1
11 0000-10-10996
Spring
1
12 042-002757-00 Front housing bracket 1
13 0000-10-10789 Optical Encoder 16 steps 5VDC Dip6 1
14 042-000693-00
Encoder mounting board
1
15 6802-20-66729 Heat conductor for the LED cover 1
16 M04-051003--- Crosshead tapping screw, PT2×6 2
17 6802-30-66682 LED board 1
18 6802-20-66690 Light conduction block 2 1
19 6802-20-66689 Light conduction block 1 1
20 6802-20-66688 Alarm LED cover 1
21 M6T-040001--- Clamp spring.1707P 1
