Mindray BeneView T5 Service Manual

6-29
Parts List
SN P/N Description Qty
1 M90-000156--- Plastic hex nut M3 2
051-000976-00 M51A Multi-parameter module, 5-lead, standard
051-000977-00 M51A Multi-parameter module, 5-lead, full
051-000978-00 M51A Multi-parameter module, 12-lead, full
2
051-001037-00
M51A Multi-parameter module, 5-lead, full, IBP,
Masimo
1
As configured
3 A21-000007--- Silicone tube 1.65 inch
4 M90-000155--- Plastic hex stud screw, M3×12 2
5 047-006240-00 Insulation sheet for SpO
2
board 1
051-000943-00 9008 V2.0 SpO
2
board
0671-00-0102-01 Nellcor SpO
2
board
6
040-001149-00 Masimo, MS-2013, SpO
2
board
1
As configured
7 M04-051001-01 Crosshead screw M3×4 2
8 6800-20-50339 Waterproof seal 02 1
9 M04-004015--- Cross pan head screw with washer M3×8 5
10 043-001964-00 Holder 1
115-011209-00 New MPM front panel assembly, Midnary SpO
2
115-011210-00 New MPM front panel assembly, Nellcor SpO
2
15-011211-00
New MPM front panel assembly, Masimo2013
SpO
2
115-011212-00
New MPM front panel assembly, Mindray SpO
2
,
no IBP
115-011213-00
New MPM front panel assembly, Nellcor SpO
2
,
no IBP
11
115-011214-00
New MPM front panel assembly, Masimo SpO
2
,
no IBP
1
As configured
12 6800-20-50394 Snap close 1
13 A90-000031--- Cable tie, CHS-4×150mm 2
14 M04-011002--- M3 nut with washer 2
115-011562-00 New M51A Infrared communication board
15
115-011563-00
New M51A Infrared communication board, no
IBP
1
As configured
16 6800-20-50292 Fixer 2
