Mindray BeneView T5 Service Manual

6-41
Parts List
SN P/N Description Qty
1 6800-20-50275 2-slot module inner housing, right side 1
2 M04-003105--- Tapping screw PT3×8 1
3 6800-30-50116 2-slot button board 1
4 6800-20-50283 2-slot module button pressing plate 1
5 6800-20-50285 2-slot module silicone button 1
6 M04-000501--- Stainless steel nut 1
7 043-000265-00 Mindray CO
2
front panel (English) 1
8 9211-30-87429 Watertrap connector assembly (ARTEMA) 1
9 6200-20-11614 Gas outlet 1
10 6800-20-50286 Locking device 2
11 M04-005005--- Crosshead screw M3×6 2
12 6800-20-50394 Latch 1
13 6800-20-50164 Module fan and cable 1
14 6800-20-50540 Module fan cushion 4
15 6800-20-50289 Fan pressing plate 1
16 M04-051003---
Tapping screw PT2.0×6
4
17 M02B-30-64513 CO
2
main unit 1
18 6800-20-50274 2-slot module inner housing, left side 1
19 6800-30-50804 Mindray CO
2
module infrared communication board 1
20 6800-20-50339 Waterproof seal 02 1
21 M04-011002--- M3 nut with spring washer 2
22 6800-20-50292 Fixer 2
23 6800-20-50278 Snap plate 2
24 6800-20-50273 2-slot module rear housing 1
25 M04-000104--- Spring washer 2
26 6800-20-50279 Infrared light filter 1
27 6800-20-50293 Screw 2
