6-31
6.9 Replaceable Parts
To replace the parts, please refer to 5 Repair and Disassembly and the exploded views above.
NOTE
z Here we list most replaceable parts. If you need more parts, please contact our
Customer Service Department.
6.9.1 Main Unit
P/N Description Qty
Front housing assembly
0000-10-11020 Backlight board 1
022-000014-00 or
022-000001-00
TPI inverter 1
0000-10-10752 LCD screen (SHARP） 1
0000-10-42633
（optional）
LCD screen（AU） 1
0000-10-10799 Touchscreen 12.1” 1
0000-10-10749
（optional）
Touchscreen 12.1” 1
6800-30-50082 Touchscreen control board 1
6800-30-51095
（optional）
Touchscreen control board
（should be used in connection with the optional
touchscreen 0000-10-10749）
1
6802-30-66812 Button (AU 12.1” screen G121SN01+anti-glare screen)
6802-30-66814 Button (AU 12.1” screen G121SN01+touchscreen)
6802-30-66682 Alarm LED board 1
6800-30-51132 Encoder assembly
6800-30-50520 Encoder assembly 1
6802-30-66680 Power switch & LED board 1
6802-20-66732 Connecting cable between converter and keypad (Sharp) 1
6802-20-66731 12” SHARP screen connecting cable 1
6802-20-66673 Cable connecting the inverter and the button board 1
6802-20-66650 Flat cable connecting the LCD and the mother board 1
6802-20-66670
Cable connecting the alarm LED board and the button
board
1
