The mother board is in charge of connections and communications with other components
and provides the following interfaces:
Name Description
LCD connector Connects the built-in display.
Video output +CIS+IO +IIC Connects the digital video interface board.
USB×2+network+RS422
+GPIO port
Connects the USB_Hub board.
Button board connector Connects the button board.
Recorder connector Connects the recorder.
CF card connector Connects the CF card assembly.
Speaker connector Connects the speaker.
Power module connector Connects the power module.
Integral module rack connector
Connects the 3-slot rack communication board in the integral
module rack.
Fan connector Connects the fan.
CPU board It is connected with the mother board through a butt socket.
Internal wireless network card
assembly
Connects the internal wireless network card.
Integral Module Rack
The patient monitor has two kinds of integral module rack: 2-slot and 5-slot. The control
board includes a NIOS II FPGA. It implements protocol conversion and infrared
communication between the main unit and the parameter modules
The module rack communication board can be a 2-slot type or a 3-slot type. The 3-slot
communication board communicates the main board directly. The 2-slot communication
board is connected with and controlled by the 3-slot communication board. The 3-slot
communication board has the function of communication control. The 2-slot communication
board consists of the infrared circuit and module power circuit. The RS422 drive circuit is
located on the 3-slot communication board.
