In the [Oxygenation Calculation] window, you can:
 Change the pressure unit, Hb unit and oxygen content unit by selecting [Press. Unit], [Hb Unit] and [OxyCont
Unit] and then selecting the appropriate settings. The changes take effect automatically.
 Trigger a recording by selecting the [Record] button. The displayed oxygenation calculations are printed out by
the recorder.
 Review the previously performed calculations by selecting [Review].
20.3.2 Entered Parameters
Abbreviation Unit Full spelling
C.O. L/min cardiac output
FiO
2
% percentage fraction of inspired oxygen
PaO
2
mmHg partial pressure of oxygen in the arteries
PaCO
2
mmHg partial pressure of carbon dioxide in the arteries
SaO
2
% arterial oxygen saturation
PvO
2
mmHg partial pressure of oxygen in venous blood
SvO
2
% venous oxygen saturation
Hb g/L hemoglobin
CaO
2
ml/L arterial oxygen content
CvO
2
ml/L venous oxygen content
VO
2
ml/min oxygen consumption
RQ None respiratory quotient
ATMP mmHg atmospheric pressure
Height cm height
Weight kg weight
20.3.3 Calculated Parameters and Formulas
Abbreviation Unit Full spelling Formula
BSA m
2
body surface area Wt
0.425
× Ht
0.725
× 0.007184
VO
2
calc ml/min oxygen consumption C(a-v)O
2
× C.O.
C(a-v)O
2
ml/L arteriovenous oxygen content difference
CaO
2
－ CvO
2
O
2
ER % oxygen extraction ratio 100×C(a-v)O
2
/ CaO
2
DO
2
ml/min oxygen transport C.O. × CaO
2
PAO
2
mmHg
partial pressure of oxygen in the alveoli
FiO
2
/ 100 × (ATMP－47)－PaCO
2
×[ FiO
2
/100
＋ (1－FiO
2
/100) / RQ ]
AaDO
2
mmHg alveolar-arterial oxygen difference
PAO
2
－ PaO
2
CcO
2
ml/L capillary oxygen content
Hb × 1.34 ＋ 0.031 × PAO
2
Qs/Qt %
venous admixture
100× [1.34 × Hb × (1－SaO
2
/100) ＋ 0.031×
(PAO
2
－PaO
2
)] / [1.34 × Hb × (1－SvO
2
/100)
＋ 0.031× (PAO
2
－ PvO
2
)]
C.O. calc L/min calculated cardiac output
VO
2
/ (CaO
2
－ CvO
2
)
