Passport 12/Passport 8 Operator’s Manual A-3
A.4 Hardware Specifications
A.4.1 Display
Host display
Screen Size
(diagonal)
Screen type Resolution
Passport 12
12.1”
color TFT LCD 800×600 pixels
Passport 8
8.4”
External display
Screen type Medical-grade TFT LCD
A.4.2 Recorder
Method Thermal dot array
Paper width
50 mm±1 mm
Paper speed 25 mm/s or 50 mm/s with accuracy within ±5%
Number of waveform channels Maximum 3
A.4.3 LEDs
Alarm lamp 1 (two color coded: yellow and red)
Power on LED 1 (green)
AC power LED 1 (green)
Battery LED 1 (green)
A.4.4 Audio Indicator
Speaker
Give alarm tones (45 to 85 dB), key tones, QRS tones; support PITCH TONE and
multi-level tone modulation; alarm tones comply with IEC60601-1-8.
A.4.5 Monitor Interface Specifications
Power 1 AC power input connector
Wired network 1 RJ45 connector, 100 Base-TX, IEEE 802.3
USB 2 connectors, USB 2.0
Equipotential Grounding Terminal 1
Multifunctional connector 1
VGA connector 1
