Mindray Passport 12 Operator's Manual

27-4 Passport 12/Passport 8 Operator’s Manual
27.2 SpO
2
Accessories
Extension Cable
Module type Remarks Part No.
Masimo 8 pins, purple connector 115-020768-00
Nellcor 8 pins 0010-20-42712
SpO
2
Sensors
Masimo SpO
2
Module
Type Model Patient Category Part No.
Disposable
LNCS Neo Neonate 0600-00-0157
LNCS Inf Infant 0600-00-0158
LNCS Pdtx Pediatric 0600-00-0122
LNCS Adtx Adult 0600-00-0121
LNCS NeoPt Neonate 0600-00-0156
Reusable
LNCS DCI Adult 0600-00-0126
LNCS DCIP Pediatric 0600-00-0127
Wavelength emitted by the sensors is between 600 nm and 1000 nm.
The maximum photic output consumption of the sensor is less than 18 mW.
The information about the wavelength range and maximum photic output consumption can be especially useful to
clinicians (for example, when photodynamic therapy is performed).
27.3 NIBP Accessories
Tubing
Type Patient Category Part No.
Reusable
Adult, pediatric, infant 6200-30-09688
Neonate 6200-30-11560
Reusable Cuff
Model Patient Category Measurement Site
Limb Circumference
(cm)
Bladder Width
(cm)
Part No.
/ Large adult (long)
Arm
35.5 to 46 / 0683-15-0007-01
/ Adult (long) 27.5 to 36.5 / 0683-15-0006-01
CM1201 Child 10 to 19 9.2 0683-15-0001-01
CM1202 Small adult 18 to 26 12.2 0683-15-0002-01
CM1203 Adult 24 to 35 15.1 0683-15-0003-01
CM1204 Large adult 33 to 47 18.3 0683-15-0004-01
CM1205 Thigh Thigh 46 to 66 22.5 0683-15-0005-01
/ Child Arm 0 to 19 / 115-027713-00
