C-14 Passport 12/Passport 8 Operator’s Manual
Item Name
Configurable
Default
In Config Mode In Monitor Mode
Hal Red
Enf Orange
Iso Purple
Des Cyan
Sev Yellow
C.O. White
X represents a waveform label, such as ECG, RESP, CO
2
and so forth. The ECG waveform cannot be set off.
C.2.4 Review
Item Name
Configurable
Default
In Config Mode In Monitor Mode
Tabular Trends
Interval No Yes
General: 30 min
OR: 5 min
ICU, NICU, CCU: 30 min
Trend Group No Yes Standard
Graphic Trends
Trend Group No Yes Standard
Zoom No Yes 90 min
Waves No Yes 2
Minitrend Length No Yes 2 h
Full Disclosure
Save Waves No Yes Save ECG1 by default.
Gain No Yes x 1
Sweep No Yes 25 mm/s
C.2.5 Event
Item Name
Configurable
Default
In Config Mode In Monitor Mode
Waveform 1 No Yes II
Waveform 2 No Yes
General, OR, ICU, CCU:
NICU
I
Pleth
Waveform 3 No Yes
General, OR, ICU, CCU:
NICU
Pleth
Resp
