Recording
8-9
8.4 Installing Recorder Paper
Installing Procedure
1. Press the latch at the upper right of the paper compartment door to releases the
door.
2. Lift the roller lever located at the upper left of the paper compartment as shown
in the following figure.
3. Insert a new roll of recorder paper into the compartment as shown below.
4. The roller of the recorder scrolls automatically, and the paper comes out of the
compartment.
5. Push down the roller lever.
6. Close the recorder door.
Figure 8-1 Installing Recorder Paper
CAUTION
z Use the specified recorder paper only. Other recorder paper may cause
the recorder to print with poor quality, function improperly or not at all,
or bring damage to the thermal print head.
z Do not pull the recorder paper with force when the printing is in process.
Otherwise, damages to the recorder may be incurred.
z Do not leave the recorder door open except you are replacing the
recorder paper or removing a fault.
Roller
To Next Page
