Appendices
20-6
Connectors
Power supply 1 AC power connector
Parameter ECG, RESP, TEMP, SPO2, NIBP, IBP, CO, CO2, AG
Network 1 standard RJ45 network connector, 100 BASE-TX
VGA 1 standard color VGA monitor connector, 15-PIN D-sub
Auxiliary output 1 BNC connector
Equipotentiality 1 equipotential grounding connector
A.5 Wireless network
Standards IEEE 802.11b, Wi-Fi compatible
Frequenct range 2.412 to 2.462GHz
China America Canada Europe Spain France Japan
1 to 11 10, 11 2
Operating channel
For other country, please refer to your local law.
Safe distance 10m (a circle centering AP with the diameter of 10m)
Maximum data rate 11Mbps
A.6 Data Storage
Trend data
Long trend: 96 hours, resolution 1min, 5 min or 10 min.
Short trend: 1 hour, resolution 1 s or 5 s.
Alarm events
70 alarm events and associated waveforms (with user
selectable waveform length 8s, 16 or 32).
ARR events 80 ARR events and associated waveforms with 8s wavelength.
NIBP measurements
800 NIBP groups, including systolic pressures, mean pressures,
diastolic pressures and measurement time.
