Recall
9-6
RESOLUTION
1. Rotate the control knob to highlight the field at the right of RESOLUTION.
2. Press the control knob, and a popup value with the options, 1MIN, 5 MIN,
10MIN, 30MIN and 60MIN, is opened.
3. The time displayed in the TIME filed changes with the resolution.
UP-DOWN
1. Rotate the control knob to highlight the UP-DOWN option, and press.
2. If the
mark is displayed at the lower right of the TIME field, you can rotate
the control knob anticlockwise to page down and review the trend data of
earlier time.
3. If the
mark is displayed at the upper right of the TIME field, you can rotate
the control knob clockwise to page up and review the trend data of later time.
L-RIGHT
1. Rotate the control knob to highlight the L-RIGHT option, and then press.
2. Rotate the control knob to select a parameters set.
The “>” mark on the right of the parameter names indicates the following page is
available, and the “<” mark on the left of the parameter names indicates the previous
page is available.
3. The parameter names and the trend data changes with the selected parameter
set.
REC
The REC option allows you to print out the trend data of the currently displayed
parameter(s).
Mark Event
If an event is marked A, B, C or D, the mark ( A, B, C or D ) will be displayed
aside the mark time on the trend table.
