ECG/RESP Monitoring
11-46
For different patient types, the upper/lower limits of the respiration rate alarm may
vary in the following range.
Patient type Max. ALM HI Min. ALM LO
Increment
Adult 120 0 1
Neonate/pediatric 150 0 1
îš„ APNEA ALM
Apnea alarm
Determines whether the patient’s cessation of breath is an
apnea event. Range: 10–40 seconds.
îš„ SWEEP
Waveform speed
Options: 6.25, 12.5 and 25.0 mm/s.
îš„ HOLD TYPE
Calculation type
Options: AUTO and MANUAL
1. AUTO: When AUTO is selected, the monitor automatically determines the
detection threshold for respiration and calculates the respiration rate. The
HOLD HI and HOLD LO options are inactive.
2. MANUAL: When MANUAL is selected, the user determines the detection
threshold for respiration and the monitor calculates the respiration rate
depending on the user-selected criteria.
îš„ DEFAULT >>
Select DEFAULT >> to access the RESP DEFAULT
CONFIG menu. You can select either FACTORY
DEFAULT CONF or USER DEFAULT CONF. After
finishing the selection and exiting the menu, a dialog pops up
asking for confirmation of your selection.
