The Basics
2-7
On the right side of the monitor, you can find the connector for Oridion or Mindray
CO
2
module or AG module. The recorder is located at the bottom of the right side.
(1) (2)
Figure 2-3 Right Side Panel
1. CO
2
: CO
2
sensor connector (Oridion CO
2
module)
2. Water trap connector (Mindray CO
2
or AG module)
3. Exhaust outlet
4. Recorder
NOTE
z Some modules are optional. Their connectors may not be available on
your patient monitor.
z Your monitor can be equipped with Oridion, Welch Allyn or Mindray CO
2
module. As shown in Figure 2-2 and Figure 2-3, they are located in
different position and have different appearance. For one monitor, only
one CO
2
module can be equipped.
z If your monitor is equipped with Mindray CO
2
module, then it can’t be
equipped with AG module, vice versa.
1
4
3
2
