Appendices
20-29
C.2.3 RESP Module Alarm Messages
Alarm message A B L Cause Measure
RESP DISTURBED No No 3 The module circuit is disturbed.
RR EXCEED No No 1 The circuit is disturbed and the
measurement is inaccurate.
If the problem occurs
continuously, restart the
monitor. If it still exits, contact
our company for repair.
C.2.4 TEMP Module Alarm Messages
Alarm message A B L Cause Measure
TEMP1 SENSOR
OFF
No Yes 3 The T1 sensor is not connected
correctly to the patient or the
monitor.
Check for correct connection of
the T1 sensor.
TEMP2 SENSOR
OFF
No Yes 3 The T2 sensor is not connected
correctly to the patient or the
monitor.
Check for correct connection of
the T2 sensor.
TEMP SELFTEST
ERROR
No No 1 Circuit fault of the temperature
channel.
Contact our company for repair.
TEMP
CALIBRATION
ERR
No No 2 Error in temperature channel
calibration.
Restart the monitor. If the error
remains, contact our company
for repair.
C.2.5 NIBP Module Alarm Messages
Alarm message A B L Cause Measure
NIBP SELFTEST
ERR
Yes Yes 1 Error in NIBP initialization. Select RESET from the NIBP
SETUP menu. If the error
remains, contact our company
for repair.
LOOSE CUFF No Yes 3 The NIBP cuff is not properly
connected.
AIR LEAK No Yes 3
PNEUMATIC
LEAK
No Yes 3
Leak in the airway.
CUFF TYPE ERR No Yes 2 The cuff applied is not
appropriate to the patient type.
AIR PRESSURE
ERROR
No Yes 3
WEAK SIGNAL No Yes 3
Failure occurs in the pulse
measurement. The monitor cannot
perform measurement, analysis,
Check the patient’s condition,
and check if the patient type is
correct. Replace with a proper
cuff and connect it correctly. If
the problem still exists, contact
our company for repair.
To Next Page
