System Menu
4-15
îš„ RT REC TIME
Real-time recording time
Options: CONTINUAL and 8s.
îš„ TIMING REC
TIME
Timing recording time
The interval between automatic recordings.
Options: OFF, 10MIN, 20MIN, 30MIN, 40MIN, 50MIN,
1HOUR, 2HOURS, 3HOURS and 4HOURS. The monitor
will start recording at the selected interval, record for 8s and
stop automatically.
NOTE
z TIMING REC TIME cannot be saved after the monitor is turned off. But it
can be saved as the user default configuration.
z RT REC TIME has priority over TIMING REC TIME.
îš„ REC RATE
Recording rate
Options: 25.0 and 50.0; unit: mm/s;
îš„ REC GRID
Recording grid
ON: You can select ON to print a grid on the recorder paper;
OFF: You can select OFF to print without grid on the
recorder paper.
îš„ CLEAR REC
TASK
Clear recording task
This key allows you to clear all current recording tasks.
For details about recording operations, see chapter 8 Recording.
