Mindray Resona 7T - Adjusting Brightness and Contrast

7-2 Adjustments
 Tilt the monitor
When positioned vertically, the monitor can be tilted 20° backward and can be tilted forward to
a horizontal position. When transporting or moving the system, keep the monitor in the
horizontal position, as shown below:
 Lock the monitor
To move the machine, first move the monitor and supporting arm to the middle position, and
lock the locking lever to
state to avoid crash.
7.1.2 Adjusting Brightness and Contrast
To avoid adjusting the gain, TGC, dynamic range and the acoustic output repeatedly, it is
necessary to set the proper brightness and contrast. The adjusting buttons are shown as follows:
 Brightness adjustment:
Press <F10 Setup>. Click [System]→[General]→[LCD] to adjust the brightness.
 Contrast adjustment:
Press <F10 Setup>. Click [System]→[General]→[LCD] to adjust the contrast.
Click “Brightness auto adjustment”. The brightness/contrast can be adjusted according to the
situation.
