4 Setup
Operator’s Manual 4 - 15
2-dimension barcode reader (2D)
• General Analysis Mode
Select “General” from “Analysis Mode” drop-down list: The scan codes consist of Patient ID,
Other ID, Patient Name, Birth, etc.
• Advanced Analysis Mode
Select “Advanced” from “Analysis Mode” drop-down list: user enters scan barcode example
and regular expression and click [Match], the system will match scan barcode example with
Move Down Move up or Move down a selected item.
Move Up
Delete Add or delete a selected item. (Only the default item can be added or deleted.)
Add
Load default Restore the parameter value to the default value.
Item Description
Item Description
Scan Barcode Example Input a barcode example, barcode example is separated by separators
(the separator is used to set the start and end position of each item), and
the barcode data is displayed in the following items in turn.
Parameters • Input a barcode example, and you can change the information of
Patient ID, Other ID, First Name, Last Name, Middle Name, Birth
(Day), Birth (Month), Birth (Year), Age, Gender and etc. in the
“Content” list.
Note:
Ignore item is used to add one line below the selected item to hide
unimportant patient information.
• Set the start and end position of each item via separators. After
inputting a barcode example, you can select item separators from the
drop-down list of the Separator. (Only separators that are input in the
field box of the Scan Barcode Example can be displayed in the drop-
down list of the Separator.)
NOTE:
You can customize the age unit of Birth (Day), Birth (Month), Birth
(Year) in the Content column. If the DOB provided by the patient
contains only digit, the system displayed an auto-generated age.
Move Down Move up or Move down a selected item.
Move Up
Delete Add or delete a selected item. (Only the default item can be added or
deleted.)
Add
Load default Restore the parameter value to the default value.
Age Unit Select an age unit from the drop-down list of the “Age Unit”: Year,
Month, or Day.
Female Input the customized gender symbol besides the Male and Female field
box, such as Male (M) or Female (F).
Male
