3 System Preparation
Operator’s Manual 3 - 9
3.7 Connecting/Disconnecting a Probe
• Press <Freeze> to freeze an image or turn off the power of the system
before connecting/disconnecting the probe. Otherwise, system or probe
failure may occur.
• When connecting or disconnecting a probe, place it in a proper position, to
prevent the probe from falling off or becoming damaged.
• Hang the probe cable to the hanger located under the control panel to
avoid excessively bending and damaging the cable.
• Only use the probes provided by Mindray. Aftermarket probes may result in
damage or cause a fire.
3.7.1 Connecting a Probe
The probes, cables and connectors should be in proper operating order and
free from surface defects, cracks and peeling. Otherwise, this may lead to
electrical shock.
Perform the following procedure:
1. Turn the knob horizontally. Keep the cable end of the transducer upwards, and insert the
connector into the port of the system, and then press in fully.
2. Turn the lock handle 90° clockwise to lock it securely.
3. Place the probe properly to avoid being treaded or wrapping around other devices. DO NOT
allow the probe head to hang free.
To Next Page
