4 Setup
Operator’s Manual 4 - 17
4.1.11 Key Probe
This page is used to set the functions of keys on the key probe by Short Press, Long Press, and
Double Click.
4.1.12 Biopsy
This page is used to set the biopsy grid parameters, such as Guide Line Dot Type, Grid Size, and
Grid Type.
4.2 Exam Mode Preset
You can assign available exam modes for probes.
Perform the following procedure:
1. To select a probe, move the cursor over the Probe column and select the probe model using the
drop-down list.
2. Select/delete exam modes:
On the left side, you can view all the available exam modes in the exam library for the probe.
On the right side of the screen, you can view the current exam modes assigned to the probe.
– Click [>]: add a selected exam mode in the [Exam Mode Library] to the [Probe and Exam
mode] list.
– Click [<]: add a selected exam mode in the [Probe and Exam Mode] to the [Exam Mode
Library] list.
– Click [>>]: add all exam modes in the library to the [Probe and Exam Mode] list.
– Click [<<]: add all probe and exam modes in the library to the [Exam Mode Library] list.
– Click [Delete] to delete a user-defined exam in the Exam Mode Library area.
– Click [Default] to set a selected exam mode as the default exam mode. The default exam
mode is marked by a “√”.
K2
K1
To Next Page
