9-30 Structure and Assembly/Disassembly
9.3.14 Bale of Wire for the Monitor/Side Control Panel
Base/Base Assembly
The disassembly tool: cross-headed screwdriver (M3, M4), inner hex spanner (M3, M5).
1. See Chapter 9.3.6, 9.3.8, 9.3.9, 9.3.10 and 9.3.12 for details.
2. Unscrew M4 X 12 cross panhead screw on UC-0.5 lock knob and UC-2 lock knob with
screwdriver (M3, M4), and unscrew one M4 X 12 cross panhead screw from the grounding
terminal of the monitor to remove the monitor cable and the rotating cap of the support arm.
3. Unscrew 2 M4 X 12 cross panhead screws from the base of the control panel with
cross-headed screwdriver (M3, M4) to remove the cover of the side board.
4. Remove the absorbing cotton insulation.
Note:
Do not tilt or block the screw holes when installing the absorbing cotton insulation
anticlockwise.
Fixation UC-0.5
F
ixation UC-2
Rotating cover of the support arm
Bale of wire
for the
monitor
