9-24 Structure and Assembly/Disassembly
2. Unscrew 4 M3 X 8 cross panhead screws from the support arm cover with the screwdriver (M3,
M4) to remove the upper and lower support arm cover (2116).
9.3.12 Support Arm Assembly
The disassembly tool: cross-headed screwdriver (M3, M4), hexagon wrench (M6)
1. Remove the display assembly (see 9.3.5).
2. Remove the M4x12 cross panhead screws (2 pcs) and take out the cable fastening block.
Cable fastening block
3. Remove the M3x8 countersunk screws (2 pcs) and take out the lower cover of the support arm.
4. Remove the M3x8 countersunk screw (1 pcs), take out the crimping plate, open the bottom
decorative cover as shown in the figure, and take the display signal line and power cord out of
the support arm.
