Mindray Resona 7T - Fusion Imaging Assembly (I0)

To Next Page

To Previous Page

Field Replaceable Unit 8-33

8.2.9 Fusion Imaging Assembly (I0)

No.

Order Number

Part Name

Qty.

Remark

I1 115-034852-00 cantilever assembly 1

I2 115-040847-00 Connect Base Assembly 1

I3 043-006786-00 Base Cover(Transport) 1

I4 801-1112-00003-00 UMT-160 Trolley Caster and Spanner(FRU) 1
