8-34 Field Replaceable Unit

No. Order Number Part Name Qty. Remark

I5 024-000703-00 3DG TrakSTAR Electronic Unit 1

I6 024-000704-00

3DG Mid-Rang Transmitter for

driveBAY/trakSTAR

I7 024-000705-00

3DG Model 800 6DOE Sensor for

driveBAY/trakSTAR

1or2
