Operator’s Manual 14 - 1
14 Measurement, Comments and
Body Mark
14.1 Measurement
There are general measurements and application measurement. You can perform measurements on
a zoomed image, cine reviewing image, real-time image, or frozen image. For measurement details,
please refer to the “Advanced Volume”.
• Be sure to measure areas of interest from the most optimal image plane to
avoid misdiagnosis from inaccurate measurement values.
• To obtain accurate Doppler flow measurement values, make sure the
transmitting beam is not perpendicular to the flow, otherwise false readings
and potential misdiagnosis may result.
• If an image is unfrozen or the mode is changed during a measurement, the
calipers and measurement data will be cleared from the screen, but the
measurement data will be stored in the report.
• If the system is turned off or [End] is selected during a measurement, the
data not saved will be lost.
• In Dual-B imaging mode, the measurement results of the merged image
may be inaccurate. Therefore, the results are provided for reference only,
not for confirming a diagnosis.
Measurement Accuracy
• Error of 2D Images
Parameter Value Range Error
Distance Full screen Within ±3%
Area Full screen Within ±7%.
Circ Full screen Within ±10%
Angle Full screen Within ±3%.
Volume Full screen Within ±10%.
