Mindray Resona 7T - Page 155

Field Replaceable Unit 8-31
No. Order Number Part Name Qty. Remark
H10 009-004567-00 TGC board signal control wires 1 Control panel,J29-TGC board
H11 009-004568-00 Signal control wire of the trackball board 1 Control panel,J1-trackboard PCBA
H12
009-004569-00
Signal wire of the trackball
1
Control panel,J2-trackball
H13 009-004570-00 signal cable for rising/dropping/locking 1 lift control board,,J5-handle panel assembly
H14 009-004592-00 control signal wires 1 Mother board,J40-lift control board,J1
H15 009-006474-00 signal wires of location 1 use for the machine V2.0 or above
H16 009-004571-00 power wires of the electromotor driven 1 lift control board,J8-drive board
H17 009-004572-00 control wires of the electromotor driven 1 lift control board,J9-drive board
H18
009-005135-00
485 signal wires
1
lift control board,J11-drive board
H19
009-004573-00
power connect
wires of the electric-magnet
1
lift control board,J2-electromagnet
H20 009-004586-00 SATA power cable for HDD 1 Mother board,J34-Hard disk
H21 009-004587-00 SATA signal cable for HDD 1 Mother board,J35-Hard disk
H22 009-004588-00 SATA cable for DVD 1 Mother board,J48-DVD
H23 009-010569-00 signal wires of the ECG module 1 Mother board,J33-ECG module
H24 009-004591-00 MIC cable 1
Mother board,J46- front-in assembly(ECG
module)
H25 009-004617-00 power wires of the LCD drive board 1
Control panel,J4- LCD signal connection board,
J3
H26 009-005134-00 5V_STB wires 1 5V board, J2-ACDC connection board,J9
H27 009-005265-00 5V AC-DC power module input wires 1 AC connection boad,J5-5V board,J1
H28 009-005336-00 12V power control wires TDK 1 ACDC Module-ACDC connection board
H29 009-005337-00 24V power control wires TDK 1 ACDC Module-ACDC connection board
