Structure and Assembly/Disassembly 9-33
3. Unscrew 4 M4 X 12 cross panhead screws on both left and right side with screwdriver (M3, M4)
to remove the cover of the support arm.
4. Unscrew 2 M4 X 12 cross panhead screws on drag chain holder-1 with screwdriver (M3, M4) to
pull the wires out.
5. Press the clip towards the arrow’s direction to disconnect the connectors of the
electromagnets.
To Next Page
