7 - 32 Operator’s Manual
7 3D/4D
Reset Ori.
Tap [Reset Ori] to reset the orientation and zoom status of the image.
7.14 SCV
+
SCV
+
is SCV (Slice Contrast View) +CMPR (Curved MPR).
SCV imaging can reduce speckle noise and improve contrast resolution as well as enhance signal-
noise ratio, which helps in discovering diffuse pathology in organs.
The curved MPR function allows straightening of a curved surface/anatomy. In clinical application,
this is usually used for imaging fetal spine.
SCV
+
imaging is not available in Smart 3D mode.
7.14.1 Basic Procedures
SCV operation
Perform the following procedure:
1. Acquire necessary 3D/4D data.
2. Tap [SCV
+
] tab on the touch screen to enter SCV imaging, and the system displays three
section images in A, B and C window.
3. Rotate the knob under [Thickness] on the touch screen to adjust imaging thickness.
4. Save images as necessary.
SCV+CMPR operation
Perform the following procedure:
1. Enter SCV
+
.
2. Tap [A], [B] or [C] to select current window.
3. Tap [CMPR] to turn on the CMPR function. Window A on main screen displays the current
window and three other windows are blank.
4. Select reference section, perform rotation and shifting operations to adjust image.
5. Tap [1], [2], or [3] button in [Active Quadrant].
6. Select trace options: tap [Line], [Trace] or [Spline].
7. Draw on the reference image. You can draw three curves at most and the CMPR imaging for
the curve are displayed in the selected [1], [2] or [3] window respectively as shown in figure
below.
