13 Display & Cine Review
Operator’s Manual 13 - 3
• In splitting display B mode, press <Dual>/user-defined <Quad> key to switch among the
windows; press <B> to exit splitting display mode and enter the image of the currently
activated window in full screen.
• In frozen mode, the system supports imaging mode switching between the sub-modes (only for
the activated window). For example, if the frozen image is of B+C+PW mode, then the system
supports imaging mode switching between B+C+PW, B+C, B+PW and B by pressing <C> or
<PW>.
• The imaging mode and parameters of an unfrozen image is the same as the corresponding one
that before frozen; but the display format is the same as the one before unfrozen.
13.4 Cine Review
The system allows you to review and edit the images prior to the image frozen. This function is
called as cine review. The magnified images can also be reviewed, and the operating method is the
same. You can perform zoom, measurements, add comments and body marks on the images being
reviewed.
The system supports manual review as well as automatic review. The default setup is Manual Cine,
but you can switch between Auto Cine and Manual Cine.
In addition, the system supports the images reviewed along with physiological unit waveforms, if
the detection of physiological unit waveforms is performed.
• The cine memory must be cleared at the end of the current patient and the
onset of the next new patient by tapping [End].
• Cine files stored in the system’s hard drive shall contain patient information,
to avoid the selection of an incorrect image file and potential misdiagnosis.
13.4.1 Entering/Exiting Cine Review
To Enter Cine Review
• The system enters the manual cine review status once press <Freeze> to freeze the image.
• Open cine files in thumbnail, iStation or Review. The system enters automatic cine review
status.
• Swipe the touch screen left or right under the mapping mode to review the cine.
To Exit Cine Review
Press <Freeze> or <B>, the system will return to image scanning and exit cine review.
13.4.2 2D Cine Review
Manual Cine Review
Enter the cine mode in 2D imaging mode. Roll the trackball, or slide the screen to view the cine.
If you move the playback mark to the left by using the trackball, the review sequence is reversed to
the image-storing sequence, thus the images are displayed in descending order. Whereas, if you
move the playback mark to the right by using the trackball, the review sequence is the same as the
image-storing sequence, thus the images are displayed in ascending order. When you review
images until the first or the last frame, further using the trackball will display the last or first frame.
