2 System Overview
Operator’s Manual 2 - 23
• Controls on the touch screen
Tap and hold the screen to enter control editing stage.
• Moving tabs on 3D/4D viewing status
On 3D/4D viewing status, tap and hold the desired tab on the touch screen, and then drag the
tab to adjust its position.
2.14 Warning Labels
The warning labels are attached to this system in order to call your attention to potential hazards.
The warning labels use the same signal words as those used in the operator’s manual. Read
operator’s manual carefully before using the system.
The name, pattern and meaning of each warning label are described as follows:
The general meaning assigned to geometric shapes, safety colors and contrast colors for safety
signs are as follows:
Function Operations
Add a control Tap to select a button to add and tap [Confirm].
Add a user-defined
control
In comment and body mark editing status, tap and then tap
[Custom] to bring out the dialogue box for adding user-defined
controls. Enter the control name and tap [OK].
Delete a control Tap of the target control and tap [Confirm] to delete.
Change the control
position
Tap and drag the control to the desired position.
Warning Labels Meaning
1. Do not place the system on a sloped surface. Otherwise the
system may slide, resulting in personal injury or the system
malfunction. Move the system slowly on the slope by two
people and make sure that the support arm is not extended.
2. DO NOT sit on the system.
3. DO NOT push the system when the casters are locked.
4. Read this information carefully before using the system.
Warning; Crushing of hands
Geometric
shape
Meaning Safety color Contrast color Graphical
symbol color
Prohibition Red White Black
Mandatory action Blue White White
To Next Page
