Mindray Resona 7T User Manual

4 Setup
Operator’s Manual 4 - 7
Intelligent Input
Set to enable the Input Method Association.
ICA/CCA && RAR
Set the measurement properties of ICA, CCA, Renal A and Aorta.
Cardiac Value Range Display
Set whether to display value range of EMINCA Study for cardiac measurement results.
4.1.5 OB
Set the relevant information regarding the fetal gestational age, fetal growth formula and fetal
weight.
To set the default formula
Perform the following procedure:
1. On the [Fetal Gestational Age], [Fetal Growth] or [Fetal Calc] page, select an OB Item in the
left column.
2. Select a formula in the right column.
3. Click [Default]. The default formula is marked with a √.
– On the [Fetal Gestational Age] page, select whether to display the SD or EDD in the
obstetric result.
– On the [Fetal Gestational Age] page, select whether to display the EFW derived GA in the
report.
To set the fetal weight display
Perform the following procedure:
1. Enter the [Fetal Calc] page.
2. Select the [Fetal Weight Unit].
Select Metric, English or English & Metric from the drop-down list.
3. Select the formula for calculating the weight percentile.
Select the formula from the drop-down list of [EFW-GP].
4. Click [Save] to confirm.
To import/export an OB Table or Formula
NOTE:
Only imported user-defined tables can be exported.
Perform the following procedure:
1. Select [Import] or [Export] on the [Fetal Gestational Age] or [Fetal Growth] page.
2. Select the drive and file path where the data is located.
3. Select the data file to load or export, click [OK] to confirm.
The imported user-defined table for FG and GA must be a *.csv file. The format of the *.csv file is
described as follows:
