Mindray Spectrum - Nurse Call Cable (3 Pin Circular to Unterminated); P;N 0012-00-1277-01;-02

Spectrum
®
/Spectrum OR
™
Service Manual 0070-10-0556-02 1 - 7
Repair Information Nurse Call Cable (3 Pin Circular to Unterminated)
1.7 Nurse Call Cable (3 Pin Circular to Unterminated)
1.7.1 P/N 0012-00-1277-01/-02
FIGURE 1-1 Nurse Call Cable (3 Pin Circular to Unterminated)
NC
NO
Common
9 ft +/- 6 in.
1
2
3
1 in +/- .13 in.
6 ft +/- 1 in
E1
E2
E3
E4
E5
E6
E7
3
2
1
Connector
shield
Circuit Board
E8
BLK
RED
WHT
Cable shield
Cable
shield
BLK
RED
WHT
