Service Manual 0070-10-0556-02 1 - 9
Repair Information Serial Port to Gas Module II/SE/SE with Spirometry Cable (P/N 0012-00-1276-XX)
1.9 Serial Port to Gas Module II/SE/SE with Spirometry
Cable (P/N 0012-00-1276-XX)
-01 12" 9 pin mini D serial to 25 pin D shell
-02 72" 9 pin mini D serial to 25 pin D shell
FIGURE 1-3 Serial Port to Gas Module II/SE/SE with Spirometry Cable
(P/N 0012-00-1276-XX)
2X +/-.131.00
L
1
5
6
9
SEE DETAIL A
DETAIL A
P1
P2
1
2
3
4
5
6-9
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
24-25
23
22
8-21
7
1-6
P2
P1
