Spectrum
®
/Spectrum OR
™
Service Manual 0070-10-0556-02 1 - 35
Repair Information Troubleshooting Menus
1.25.12 Alarm Troubleshooting
BIS: Check SQI Level EMG Bar indicates electrical activity that
may be interfering with EEG recognition.
If EMG bar is illuminated,
attempt to determine and
eliminate cause.
Defective PIC. Verify Sensor Check passes. If
not, replace PIC.
Defective BISx. Replace the BISx.
NOTE: This message is displayed when
the Signal Quality is less than half of the
level desirable for optimal monitoring
conditions or when the signal quality is
too low to accurately calculate a BIS
value. This may occur as the result of
artifact (non-EEG signal) such as that
generated from motion (patient
movement or eye blinks) or the presence
of electrocautery, warming blankets, or
other devices.
BIS: Invalid Sensor Poor or contaminated connection
between sensor and PIC.
Connect/clean connection
between sensor and PIC.
Defective sensor. Replace the sensor.
Defective PIC. Replace the PIC.
Defective BISx. Replace the BISx.
BIS: Noise The signal from the electrode goes
beyond the measurable range
Re-prep the electrodes and
check all connections.
MESSAGE/
PROBLEM REASON SOLUTION
MESSAGE/PROBLEM REASON SOLUTION
High or Low or No Alarm
Sound
Alarm limits not set Go to Alarm Setup and adjust
alarms
Alarm Mute All, On time has
not expired
Press MUTE ALL to reactivate
alarms
No Arrhythmia
Alarm Sound
Arrhythmia option not installed Call Sales Rep to purchase option
Arrhythmia Alarms off Go to Monitor Setup /
Advanced Setup to activate
alarm
Monitor is in learning mode Wait until learning is concluded
and monitor patient closely
Alarms continue to Sound
despite pressing MUTE
More than one alarm is active Press MUTE or MUTE ALL key to
silence
Check Patient
No Alarm printout with
Alarm violation
Print on Alarm is set to Off Go to Print Menu and set Print
on Alarm to On
