Mindray Spectrum - Serial Port to RJ 45 Cable (VISA)

Serial Port to RJ 45 Cable (VISA) Repair Information
1 - 20 0070-10-0556-02 Spectrum
®
/Spectrum OR
™
Service Manual
1.21 Serial Port to RJ 45 Cable (VISA)
P/N 0012-00-1299-01, Spectrum
®
only
FIGURE 1-16 Serial Port to RJ 45 Cable (VISA)
P1
1
2
3
4
5
6-9
P2
1-2
3
5
6-9
Connector shield
Cable shield
N.C.
N.C.
N.C.
N.C.
N.C.
4
