Mindray Spectrum - Spo 2 Troubleshooting

Troubleshooting Menus Repair Information
1 - 26 0070-10-0556-02 Spectrum
®
/Spectrum OR
™
Service Manual
1.25.3 SpO
2
Troubleshooting
MESSAGE/PROBLEM REASON SOLUTION
SpO
2
: No Sensor Sensor is not plugged in to the
Spectrum.
Plug the sensor into the monitor.
SpO
2
: Sensor Off
(Masimo SET
®
Only)
Sensor may not be connected to
the patient.
Check patient connection.
SpO
2
: Interference Noise detected on the pulse
signal prevents pulse
discrimination.
Decrease patient motion, check
sensor.
SpO
2
: Pulse Search Hardware settings are being
adjusted in order to discriminate
a pulse waveform.
Change to site where pulse is
stronger if patient is
vasoconstricted. Change or
readjust sensor if loose.
SpO
2
: No Pulse (Nellcor
Only)
No detectable pulse is measured Check to patient connection and
patient status.
SpO
2
: Failure The system has detected an
unrecoverable failure of the
SpO
2
system.
Power cycle unit. If message
reappears, contact Customer
Support.
SpO
2
: Low Perfusion
(Masimo SET Only)
Patient perfusion is low. Check to patient connection and
patient status.
SpO
2
: Too Much Light
(Masimo SET Only)
There is too much ambient room
light for the sensor to function
properly
Minimize the room light around
the patient. Check sensor.
SpO
2
: Unrecognized
Sensor (Masimo SET Only)
The sensor is not recognized by
the Monitor.
Replace the sensor with a
recommended sensor.
SpO
2
: Communication
Error
The monitor and the SpO
2
modules are not communicating
properly.
Power cycle unit. If problem
persists, contact Customer
Support.
SpO
2
: Board Fault Masimo SET board failed to
operate properly.
See Proper Service Menu:
Suggestion.
SpO
2
: Sensor Fault Defective Sensor. Replace Sensor.
SpO
2
: Motion (Nellcor
Only)
Motion is detected Decrease patient motion, check
sensor.
SpO
2
: Check Sensor
(Nellcor Only)
The SpO
2
module has sensed a
poor connection or a bad sensor
Reconnect the same sensor. If
problem persists, replace sensor
Unable to obtain SpO
2
reading
Patient has poor perfusion. Switch limbs / Notify physician.
Sensor not on Patient. Reapply sensor.
Cables loose / not connected. Check connections, switch cable.
Ambient light. Switch limbs and cover sensor
with opaque material.
No SpO
2
waveform Waveform not selected to
Display.
Go to the Display Setup
Menu, choose to display Pleth
in the waveform area.
Cable or sensor not plugged in Check cable and sensor
Low amplitude SpO
2
signal
SpO
2
sensor on same limb as
cuff.
Check sensor placement, move
as necessary.
Patient has poor perfusion. Switch limb / Notify physician.
