Mindray Spectrum - IABP Cable; ECG Only; ECG;IBP (Only for Serial Numbers MSXXXXX-K5 and Higher)

Spectrum
®
/Spectrum OR
™
Service Manual 0070-10-0556-02 1 - 19
Repair Information IABP Cable
1.20 IABP Cable
1.20.1 ECG Only
FIGURE 1-14 IABP Cable (ECG Only) (P/N 0012-00-1459-01)
1.20.2 ECG/IBP (only for serial numbers MSXXXXX-K5 and higher)
FIGURE 1-15 IABP Cable (ECG/IBP) (P/N 0012-00-1650-01)
Connector shell
Shield drain wire
BLK
WHT
RED
AOUT1 (ECG) 1
AOUT2 (PRESS) 2
GNDA 3
AIN 4
GND 5
DOUT 6
P2, ECG
P3, PRESS
P1
TIP
SLV
RING
TIP
SLV
RING
BLK
BRN
BLK
BRN
See Note
N.C.
N.C.
N.C.
1
2
3
4
5
6
P1
2
4
1
P2
P3
3
5
5
5
