Service Manual 0070-10-0556-02 4 - 5
Calibration Procedure Diagnostics
4.4.2 Recorder Test
Select the Chart Grid ASCII Characters menu.
FIGURE 4-4 Recorder Test Menu
The printer will print the Recorder Test pattern as shown in the figure below.
FIGURE 4-5 Recorder Test Strip
