Spectrum
®
/Spectrum OR
™
Service Manual 0070-10-0556-02 3 - 27
Isometric Drawings and Part List External Parameter Module
ITEM NO DESCRIPTION PART NUMBER
1 Housing, Top, External Module 0380-00-0413
2 Housing, Bottom, External Module 0380-00-0414
3 Gasket Handle 0380-00-0416
4 Handle 0367-00-0061
5 Shaft Precision Increment 1/8 Dia X 1.250 Long 0226-04-0420
6 FFC Assembly Keypad 0331-00-0118
7 PCB Assembly, Main, External Module 0670-00-0734-01
8 PCB Assembly, Connector Panel, External Module 0670-00-0738-01
9 Button Latch External Module 0380-00-0415
10 Spring Compression 0214-00-0234
11 Screw, Pan Head Cross Recessed #4-40 X 1.25 0212-12-0420
12 Screw, Pan Head Cross Recessed #6-32 X 5/16 0212-12-0605
13 Label, Information External Module 0334-00-2583
14 Label, Patient Connector (T2, IBP3, IBP4, CO)
English, Japanese, Br. Portuguese
0334-00-2582-001
14 Label, Patient Connector (T2, IBP3, IBP4)
English, German, Italian, Japanese, Br. Portuguese
0334-00-2582-002
14 Label, Patient Connector (T2, CO)
English, Dutch, Japanese, Br. Portuguese
0334-00-2582-003
14 Label, Patient Connector (T2)
English, German, French, Spanish, Italian, Dutch,
Japanese, Br. Portuguese
0334-00-2582-004
14 Label, Patient Connector (T2, IBP3, IBP4, CO)
German
0334-00-2582-006
14 Label, Patient Connector (T2, CO)
German
0334-00-2582-008
14 Label, Patient Connector (T2, IBP3, IBP4, CO)
French
0334-00-2582-011
14 Label, Patient Connector (T2, IBP3, IBP4) French 0334-00-2582-012
14 Label, Patient Connector (T2, CO)
French
0334-00-2582-013
14 Label, Patient Connector (T2, IBP3, IBP4, CO)
Spanish
0334-00-2582-016
14 Label, Patient Connector (T2, IBP3, IBP4) Spanish 0334-00-2582-017
14 Label, Patient Connector (T2, IBP3, IBP4, CO)
Italian
0334-00-2582-021
14 Label, Patient Connector (T2, CO)
Spanish, Italian
0334-00-2582-023
14 Label, Patient Connector (T2, IBP3, IBP4, CO)
Dutch
0334-00-2582-026
14 Label, Patient Connector (T2, IBP3, IBP4)
Dutch
0334-00-2582-027
15 Label, Keypad Filler 0334-00-2624
16 Label, Part Number/Serial Number N/A
