Spectrum
®
/Spectrum OR
™
Service Manual 0070-10-0556-02 3 - 33
Isometric Drawings and Part List Comm-Port
ITEM NO DESCRIPTION PART NUMBER
1 Housing Top Base Station 0380-00-0340
2 Housing Bottom Base Station 0380-00-0341
3 Latch Base Station 0380-00-0342
4 Lever Base Station 0380-00-0343
5 Carriage Base Station 0380-00-0344
6 Bezel Base Station 0380-00-0323
7 Connector Panel Rear 0386-00-0323
8 Slide Dashpot (Plastic Part) 0406-00-0737
9 PCB Assy Main Board 0670-00-0758-01
10 PCB Assy Daughter Board 0670-00-0759-01
11 Standoff Hex Male/Female (4-40 x .748 Lg) 0361-00-0182
12 Dashpot 0103-00-0466
13 Bracket Mounting Dashpot Base Station 0406-00-0738
14 Bracket Main Connector Ground 0406-00-0841
15 Pin Monitor Guide 0226-00-0016
16 Tubing Silicone Rubber 3/8 I.D. X 1/16 Wall 0008-00-0321
17 Spring Extension .375 Dia. 1.5 Length 0214-00-0235
18 Spring Compression .296 Dia. 1.281 Length 0214-00-0234
19 Socket Guide Docking Connector 0132-00-0077
20 Screw Pan Hd 4-40 x .25 Lg 0212-12-0404
21 Screw Pan Hd 4-40 x .75 Lg 0212-12-0412
22 Screw Pan Hd 6-32 x .50 Lg 0212-12-0608
23 Screw Pan Hd 6-32 x .31 Lg 0212-12-0605
24 Screw Shoulder #6 Thread .156 Dia x 0.187
Height
0217-00-0012
25 Nut Plain Hex #4 Small Pattern 0223-02-0004
26 Washer Snubbing Mylar 0221-00-1016
27 Washer Flat Large O.D. #4 0221-00-1010
28 Label Function Diagram Base Station 0334-00-1511
29 Label Information Base Station 0334-00-1497
30 Label Dashpot Adjustment 0334-00-1618
31 Label, Latch, Locked/Unlocked 0334-00-2514
32 Bumper (Feet Base Station) 0348-03-0001
33 Standoff Hex Male/Female With Lock Washer 0361-00-0164
34 Label Part Number Serial Number N/A
35 Power Supply Assembly 0014-00-0070
36 Dashpot Assembly 0103-00-0465
NS MB1 Connector Shroud 0334-00-1668
N.A. Not Available
