4 - 32 Operator’s Manual
4 Setup
TIP:
• If the server software supports the compression algorithm, select JPEG, RLE, JPEG2000.
Otherwise, original data should be used (RLE is the default method).
• RLE, JPEG and JPEG2000 are not supported by all SCPs. Refer to the SCP’s DICOM
CONFORMANCE STATEMENT electronic file to check whether SCP supports it or not. Do
not select these compression modes if the storage server does not support them.
• Images of PW/M mode (B image is not frozen) and images other than PW/M mode: if “Max
Frame rate” is not “Full” and the actual frame rate is larger than the set value, the system will
save the image files in a frame rate of the set value, and transfer in a frame rate of B mode.
• Images of PW/M mode (B image is frozen), the system will save/transfer the images files in
frame rate of 6.
Print Service Preset
DICOM print preset items are described as follows:
Encapsulated PDF Select if to encapsulate PDF format report in DICOM standard.
It becomes available if SCP supports the function.
Storage mode Set the storage mode for image and cine file:
• Parallel file: save the current file, and is ready for the storage of the next
file.
• Parallel frame: send the current frame, and is ready for sending the next
frame.
Transducer
Tracking
Files of images that are saved in DCM format through DICOM or
DICOMDIR contain transducer serial number information.
Strategy Name Select the preset DICOM strategy.
Item Description
Item Description
Device After you set the server (s) in DICOM Preset screen, the name (s) will
appear in the drop-down list, select the name of the print server.
Service Name Default is xxx-Print, user-changeable.
AE Title Application Entity title, here, it should be consistent with that of the
print server.
Port DICOM communication port, 104 is default. Here, the port should be
consistent with that of the print server port.
Maximum Retries It starts retrying if it fails to send DICOM task to the server. The retry
entry times should be this value.
Interval Time (s) Reserved time.
Timeout Refers to the amount of time after which the system will stop trying to
establish a connection to the service.
TLS Transport Layer Security. Select whether to encrypt the data during
network transportation.
Copies Refer to copies of printed files. You can select among 1 through 5, or
directly enter the numeral.
