15. Specification | 139
15 Specification
15.1 Equipment supplied
Ser. no. Name
1 Transmitter
2 Safety instructions 9499 059 40001
15.2 General technical data
The following characteristics are valid after a warm-up time of at least 60min
utes (reference temperature23°C).
15.2.1 Date/time buffer
The lithium battery as a buffer for the date/time chip and as a buffer for the
supply voltage so the device can be switched on again.
Device continuously connected to
mains voltage
up to 10 yearsLifespan
Device not connected to mains
voltage for some time (e.g.in
storage)
up to 7 years
15.2.2 Touch Display
Type Size Display
TFT Color touch display 1.77" 128×160 pixels
15.2.3 Supply voltage connection version 24VDC
Supply voltage U
DC
=24 V +10/-15%
Max. power consump
tion
9 W
