4. Device installation | 4.3 - Hardware construction | 55
Technical data (continued)
Description Data
Cable length 10m@10Mbps, 1200m@156kbps
Certificates
– Description of product: Anybus Compact
Com 40 CC-Link
– Type: ABCC-M40-CCL
– Ver. : Hardware: 1.1, Software: 1.01
– CC-Link: 1.10/2.0
– Reference Number: 934
Note: The CSPP file is available to download online:
http://www.minebea-intec.com
Allocation of the 5-pin plug connector
Pin assignment Signal Description
1 DA Communication RS-485 RxD/TxD (+)
2 DB Communication RS-485 RxD/TxD (–)
3 GND digital ground
4 S Cable screen
5 PE, according to AnyBus S-
specification
Housing ground
4.3.10 ProfiNet I/O interface
The ProfiNet I/O fieldbus is a complete ProfiNet I/O adapter (slave) with CAN
controller.
The interface can be configured by software.
