4. Device installation | 29
4 Device installation
4.1 General instructions
Before starting work, please read Chapter 2 and follow all instructions.
WARNING
Warning of hazardous area and/or personal injury
Installation work must be performed by trained and qualified
personnel who are aware of and able to deal with the related
hazards and take suitable measures for self-protection.
WARNING
Warning of hazardous area and/or personal injury
All cable connections must be protected from damage.
Note:
– Measurement cables should be kept away from power equipment.
– Signal cables and measurement cables should be installed separately
from electric power lines.
– Measurement cables should be laid in separate cable conduits.
– Network cables should be crossed perpendicularly.
Further procedures:
– Check the consignment: make sure that all components are present.
– Safety check: inspect all components for damage.
– Make sure that the on-site installation is correct and complete including
cables, e.g. power cable fuse protection, platform scale, load cells, junc
tion box, data cables, console/cabinet, etc.
– Also mount plug-in cards where appropriate (instrument must be discon
nected from all sources of power).
– Follow all device installation instructions related to application, safety,
ventilation, sealing and environmental influences.
– Connect the cable from the junction box or platform scale/load cell.
– Connect additional data cables/network cables etc. as needed.
– Connect the supply voltage.
– Check the installation.
