6. Operating | 6.12 - Configuring the analog output | 93

6.12 Configuring the analog output

The weight value of the weighing point is transmitted to the output.

: [Analog output] or [CombiCard]

The analog output can be configured according to the table below.

Parameter table

Parameter Selection Description

[Off] Analog output is unused.

[Transparent] Value output in D30.

Instrument is controlled via PLC.

[Gross] Gross weight output in D8.

[Net] Net weight output in D9; only if tared, other

wise gross weight is output.

[Mode]

[Select] Gross/net value output on the display (D11) de

pending on SPM bit X72.

[0…20mA] Outputs 0…20mA.[Range]

[4…20mA] Outputs 4…20mA.

[Hold] If an error occurs, the analog output retains

the last value.

[0mA] If an error occurs, the analog output is set to

0mA.

[4mA] If an error occurs, the analog output is set to

4mA.

[Output on wgt. err.]

[20mA] If an error occurs, the analog output is set to

20mA.
