Minebea Intec MiNexx-link-E PR 5215/01 User Manual

6. Operating | 6.12 - Configuring the analog output | 94
Parameter table (continued)
Parameter Selection Description
[linear] In the event of a negative weight, the analog
output is retained. This is only possible if the
output value for the zero weight is >0mA.
[0mA] In the event of a negative weight, the analog
output is set to 0mA.
[4mA] In the event of a negative weight, the analog
output is set to 4mA.
[On <0]
[20mA] In the event of a negative weight, the analog
output is set to 20mA.
[linear] In the event of a weight >Max, the analog out
put is retained. This is only possible if the out
put value for Max is <20 mA.
[0mA] In the event of a weight >Max, the output is set
to 0mA.
[4mA] In the event of a weight >Max, the output is set
to 4mA.
[On > Max]
[20mA] In the event of a weight >Max, the output is set
to 20mA.
[Analog value] Input: fixed analog val
ue
Only possible if [Transparent] mode is selected.
[Weight value at
0/4mA]
Input: Weight value Weight value at which the analog output
should display 0mA.
or
Weight value at which the analog output
should display 4mA (for the analog range 4…
20mA).
[Weight value at
20mA]
Input: Weight value Weight value at which the analog output
should display 20mA.
[Adjust for 4mA] Input: Weight value Value at 4mA.
[Adjust for 20mA] Input: Weight value Value at 20mA.
